UPO2072E Digital Storage 2 Channel Analog Oscilloscope 100MHz Uni-T
by Uni-T
SKU 488951
MPN: UPO2072E
Availability:
Out of stock
Sold out
Original price
£433.22
-
Original price
£433.22
Original price
£433.22
Inc VAT
£433.22
-
£433.22
Current price
£433.22
Inc VAT
The UPO2072E offers unprecedented value in customer applications with its innovative technology, industry leading specifications, powerful trigger functions and broad analysis capabilities. The oscilloscope features 70MHz bandwidth and 4 analog channels. It adopts UNI-T UPO visualization technology, has a maximum sample rate of 1GSa/s and a standard memory depth of 56Mpts. It comes with a minimum vertical scale input range of 1mV/div, an innovative digital trigger system with high sensitivity and low jitier, waveform capture rate of 80,000wfms/s.
Bandwidth: 70MHz Real time sample rate: 1GSa/s 2 analog channels Maximum memory depth: 56 Mpts Digital fluorescent display Excellent storage depth Up to 80,000wfms/s waveform capture rate Independent time base adjustable Rich data measurement functions 8" display
Specification
Back order lead time | 10 Days |
Bandwidth | 100MHz |
Channels | 2 Analogue |
Digitalanalogue | Digital |
Display | 8 Inch TFT LCD |
Memory depth | 56Mpts |
Rise time | <5ns |
Sampling rate | 1GSa/s |
Vertical range | 1mV/div to 20V/div |
Waveform capture rate | 80,000 wfms/s |
