6-Way 5.00mm PCB Terminal Block Grey 20A 300V
by PTR HARTMANN
SKU 487438
MPN: AK700/06-5,0-GREY
Availability:
800 in stock
Original price
£0
Original price
£0.87
-
Original price
£0.87
Original price
Current price
£0.87(inc. VAT)
£0.87
-
£0.87
Current price
£0.87
Quantity Discounts
| Buy 25 - 99 | Get 13% off | £0.76(inc. VAT) each |
| Buy 100 - 249 | Get 21% off | £0.69(inc. VAT) each |
| Buy 250 - 499 | Get 28% off | £0.63(inc. VAT) each |
| Buy 500+ | Get 33% off | £0.58(inc. VAT) each |
6 pole PCB terminal block manufactured by PTR HARTMANN, featuring a 5mm pitch and parallel wire entry to the board. The terminal blocks are rated up to 20A, making them suitable for a wide range of PCB applications.
6 pole 5.00mm pitch Wire entry parallel to the board Material: PA66 Rating: 20A 300V Wire size: 30-12AWG
Specification
| Back Order Lead Time | 10 Days |
| Colour | Grey |
| Contact Material | Brass |
| Current Rating | 20A |
| Housing Material | PA66 |
| Mounting Type | PCB Mount |
| Number of Ways | 6 |
| Operating Temperature | -40°C to +105°C |
| Pitch | 5.00mm |
| Termination Method | Screw |
| Voltage Rating | 300VAC |
| Wire Range | 30-12AWG |
