VTX-126-012-215 Chassis Mount Transformer 230V 12VA 15V+15V Vigortronix
by Vigortronix
SKU 480245
MPN: VTX-126-012-215
Availability:
9 in stock
Original price
£15.21
-
Original price
£15.21
Original price
£15.21
£15.21
-
£15.21
Current price
£15.21
The VTX-126-012-215 is a high quality chassis mount transformer featuring a single 230V primary winding and 15V twin secondary winding. The transformer features 12VA power and can be connected in series or parallel.
Double section metric bobbins
Primary winding: 230V
Secondary winding: 15V+15V
Power: 12VA
Dielectric strength: 3750Vrms
Manufactured and tested in accordance to EN61558, EN60950, CE
Specification
| Back Order Lead Time | 5 Days |
| Dielectric Strength | 3750Vrms |
| Height | 45mm |
| Length | 60mm |
| Output Current | 0.4A |
| Power | 12VA |
| Primary Voltage | 230VAC |
| Secondary Voltage | 15V+15V |
| Weight | 390g |
| Width | 50mm |
