UPO2102 Digital Storage 2 Channel Analog Oscilloscope 100MHz Uni-T
by Uni-T
SKU 488947
MPN: UPO2102
Availability:
Out of stock
Sold out
Original price
£789.31
-
Original price
£789.31
Original price
£789.31
£789.31
-
£789.31
Current price
£789.31
The UPO2102 digital phosphor oscilloscope is a multifunctional and high-performance oscilloscope based on UNI-T's original Ultra Phosphor technology. It provides the combination of ease of use, excellent technical indicators and many functional features. It can help users complete the measurement work faster and more efficiently. It is an oscilloscope designed for general design / debugging / testing needs in many fields, such as communication, semiconductor, computer, instrumentation, industrial electronics, consumer electronics, automotive electronics, on-site maintenance, R&D, education, etc. Fast Acquire technology can accurately capture abnormal events such as video, jitter, noise and low wave signals.
Bandwidth: 100MHz Real time sample rate: 2GSa/s Waveform capture rate: 1.000,000wfms/s 2 analog channels 4M pts enhanced FFT Web control LA logic analyzer Bode plot AWG function arbitrary waveform generator Area trigger Full memory hardware decoding Rich trigger function Memory depth 56Mpts per channel Channel split screen function 256-level grayscale display Ultra high capture rate XY mode Rich measurement functions 8-inch interactive touch screen
Specification
| Back Order Lead Time | 10 Days |
| Bandwidth | 100MHz |
| Channels | 2 Analogue |
| Digital/Analogue | Digital |
| Display | 8 Inch Touch Screen |
| Memory Depth | 56Mpts |
| Rise Time | <3.5ns |
| Sampling Rate | 2GSa/s |
| Vertical Range | 500uV/div to 20V/div |
| Waveform Capture Rate | 1,000,000 wfms/s |
