MSO3352E 2 Analog 16 Digital Channel Oscilloscope Touch Screen 350MHz Uni-T

The MSO3352E digital phosphor oscilloscope is a multifunctional and high-performanceoscilloscope based on UNI-T's original Ultra Phosphor 2.0 technology. It realizes the combinationof ease of use, excellent technical indicators and many functional features. It can help users complete the measurement work faster. It is an oscilloscope designed for general design / debugging / testing needs in many fields, such as communication, semiconductor, computer, instrumentation, industrial electronics, consumer electronics, automotive electronics, on-site maintenance, R & D / education, etc. Fast Acquire technology can accurately capture abnormal events such as video, jitter, noise and low wave signals.

Bandwidth: 350MHz

Real time sample rate: 2.5GSa/s

Waveform capture rate: 1,000,000 wfms/s

2 analog channels, 16 digital channels

Maximum memory depth: 250Mpts

8 inch interactive touch screen

Rich measurement functions

XY mode

Ultra high capture rate

256-level grayscale display

Channel split screen function Multi-Scopes 2.0

Memory depth 70Mpts per channel

Rich trigger function

Full memory hardware decoding

Area trigger

Bode plot

LA Logic Analyzer
