DMR12TV APEM 10-Way Surface Mount 2.54mm DIP Switch SPST
by APEM
SKU 487435
MPN: DMR12TV
Availability:
885 in stock
Original price
£0.73
-
Original price
£0.73
Original price
£0.73
Inc VAT
£0.73
-
£0.73
Current price
£0.73
Inc VAT
The DMR12TV is a 12 way surface mount DIP switch featuring SPST contacts and gold plated terminals. The switch features self-cleaning contacts and 25mA 24VDC rating, suitable for PCB applications.
Recessed actuator 12 ways Switch rating: 25mA 24VDC Contact rating: 100mA 50VDC Gold plated terminals 2.54mm pitch Tape seal
Specification
| Actuation | Latching |
| Back order lead time | 10 Days |
| Colour | Black |
| Contact configuration | SPST |
| Contact material | Gold Plated |
| Contact rating | 100mA 50VDC |
| Current rating | 25mA |
| Electrical life | 2,000 Cycles |
| Material | UL94-V0 |
| Mounting style | Surface Mount |
| Number of positions | 2 |
| Number of ways | 10 |
| Operating temperature | -40°C to +85°C |
| Pitch | 2.54mm |
| Product series | DM |
| Switch operation | On-Off |
| Terminal type | Solder |
| Voltage rating | 24VDC |
