500K Linear Stereo Right Angle PCB 16mm Potentiometer
SKU 484836
MPN: 484836
Availability:
993 in stock
Original price
£0.64
-
Original price
£0.64
Original price
£0.64
£0.64
-
£0.64
Current price
£0.64
500k linear stereo potentiometer featuring right angle PCB contacts and splined 6mm shaft.
Standard 16mm diameter size 20% tolerance Panel cut-out: 7mm 5mm pitch 15mm shaft length
Specification
| Back Order Lead Time | 45 Days |
| Dimensions | 17mm Diameter |
| Maximum Voltage | 200V |
| Mounting Hole Diameter | 7mm |
| Mounting Type | PCB |
| Operating Temperature | -25°C to +70°C |
| Pitch | 5mm |
| Power Rating | 0.125W |
| Resistance | 500KΩ |
| Shaft Diameter | 6mm |
| Taper | Linear |
| Termination Type | Pin |
| Tolerance | ±20% |
| Total Rotation | 300° |
