470R Arcol 25W Aluminium Clad Resistor HS25
by Arcol
SKU 399020
MPN:
Availability:
18 in stock
Original price
£2.03
-
Original price
£2.03
Original price
£2.03
£2.03
-
£2.03
Current price
£2.03
Arcol 25W aluminium clad resistors suitable for a wide range of applications where a high power dissipation is required. The resistors have a small package and are designed for direct heatsink mounting.
High power to volume
Wound to maximise high pulse capability 5% tolerance Solder terminations Features 2 mounting holes Arcol HS series
Specification
| Back Order Lead Time | 10 Days |
| Dimensions | 51.0 x 28.0 x 14.6mm (Length x Width x Height) |
| Heatsink Area | 535cm² |
| Limiting Element Voltage | 550V |
| mpn | HS25 470R J |
| Operating Temperature | -55°C to +200°C |
| Packaging | Bulk |
| Power Rating | 25W |
| Resistance | 470Ω |
| Temperature Coefficient | ±100ppm/°C |
| Termination | Solder Lug |
| Tolerance | ±5% |
