2 Pole JST XH Top Entry Male Connector 2.5mm
SKU 550376
MPN: 550376
Availability:
1104 in stock
Original price
£0.12
-
Original price
£0.12
Original price
£0.12
£0.12
-
£0.12
Current price
£0.12
2 way pin header with 2.5mm pitch suitable for connecting wires to PCBs. The headers feature a friction lock to ensure secure retention when mated and are suitable for replacing JST XH connectors.
2.5mm pitch Solder termination Nylon-66 housing Tin plated bronze contacts Rated Current: 3A Rated Voltage: 250V
Specification
| Back Order Lead Time | 45 Days |
| Contact Material | Tin Plated Phosphor Bronze |
| Current Rating | 3A |
| Housing Material | PA66 |
| MOQ | 5 |
| Mounting Type | PCB Mount |
| Number of Ways | 2 |
| Operating Temperature | -25°C to +85°C |
| Pitch | 2.5mm |
| Termination Method | Solder |
| Voltage Rating | 250VAC |
