12V 8-Channel Relay Board Module Active Low
SKU 309025
MPN: 309025
Availability:
41 in stock
Original price
£7.45
-
Original price
£7.45
Original price
£7.45
£7.45
-
£7.45
Current price
£7.45
Active low relay board with 12V relays capable of being switched on-off by an opto-isolated digital input. The relays are controlled by a microcontroller connected to the output pin and require a minimum 1.5V to switch the inputs ON. Suitable for 5V and 3.3V devices, these boards are perfect for Raspberry Pi, Arduino, PIC and various other microcontrollers.
8 Channel Maximum switching voltage: 250VAC / 30VDC Maximum switching current: 10A Module operating voltage: 12V Each relay features an LED indicator Dimensions: 138 x 56 x 18mm (Length x Width x Height)
Specification
| Back Order Lead Time | 30 Days |
| Coil Voltage | 12VDC |
| Number of Channels | 8 |
| Terminal Type | Pin Header |
