1000pF 50V X7R 0805 5.08mm Radial Ceramic Capacitor 10%
SKU 482972
MPN: JYM
Availability:
3518 in stock
Original price
£0.08
-
Original price
£0.08
Original price
£0.08
£0.08
-
£0.08
Current price
£0.08
1nF 50V radial leaded multilayer ceramic capacitor housed in a miniature 0805 package. The capacitors feature an epoxy coating providing excellent humidity resistance and prevents damage during soldering. Suitable for blocking, coupling and by-passing applications requiring stable performance.
±10% tolerance X7R dielectric 5.08mm pitch Epoxy coating
Specification
| Back Order Lead Time | 45 Days |
| Capacitance | 1nF |
| Dielectric | X7R |
| Length | 4.2mm |
| Material | Ceramic |
| MOQ | 10 |
| Mounting Style | Through Hole |
| Operating Temperature | -55°C to +125°C |
| Package | 0805 |
| Pitch | 5.08mm |
| Thickness | 3.0mm |
| Tolerance | ±10% |
| Voltage Rating | 50V |
| Width | 3.8mm |
