0.68uF 50V Y5V 0805 2.54mm Radial Ceramic Capacitor 20%
SKU 482950
MPN: JYM
Availability:
4814 in stock
Original price
£0.12
-
Original price
£0.12
Original price
£0.12
£0.12
-
£0.12
Current price
£0.12
680nF 50V radial leaded multilayer ceramic capacitor housed in a miniature 0805 package. The capacitors feature an epoxy coating providing excellent humidity resistance and prevents damage during soldering. Suitable for blocking, coupling and by-passing applications requiring stable performance.
±20% tolerance Y5V dielectric 2.54mm pitch Epoxy coating
Specification
| Back Order Lead Time | 45 Days |
| Capacitance | 680nF |
| Dielectric | Y5V |
| Length | 4.2mm |
| Material | Ceramic |
| MOQ | 10 |
| Mounting Style | Through Hole |
| Operating Temperature | -25°C to +85°C |
| Package | 0805 |
| Pitch | 2.54mm |
| Thickness | 3.0mm |
| Tolerance | ±20% |
| Voltage Rating | 50V |
| Width | 3.8mm |
